Vertical Turbine

☆Features & Benefits

The vertical Turbine Pumps have been specifically designed for applications requiring high flow rates of LNG as well as meeting high differential head requirement. The VT pump line reaches efficiencies of over 70%. Because it uses a highly efficient permanent magnet motor the foot print is small thus reducing the overall cost of the installation, particularly in in-tank applications where the column diameter(pump well size) can be minimized.
The target market for this product line is LNG bunkering in all its different applications, from ship to ship, barge to ship or bunkering rail tender cars; flexible performance achieved through a VFD.

● Highly efficient, over 70%- lower operating costs and heat input into the fluid.
● Modular design,discharge pressure 60 PSI/stage – easily accommodates higher pressure requirements
● Compact design – minimizes pump well size resulting in lower overall installation cost
● High performance inducer – minimum NPSH requirements
● Dynamic thrust balance device – 15,000 hour bearing life design
● Electrical quick disconnect – ease of maintenance
● No Castings all machined parts

☆A(yù)pplications

LNG Bunkering、Storage transfer and pipeline injection for LNG peak shaving plants、LNG storage tank refilling、LNG circulation、Pipeline backup、Send out

☆Liquids Pumped

Liquid Nitrogen、Liquid Argon、Ethylene、Ethane、Methane (LNG)、Propane

☆Type

VT
